DF2030 High Efficiency Pellet 3D Printing Equipment for Mold Making
DF series pellet 3D printing equipment produces tooling, molds and sculptures using thermoplastic and composite pellets.
- Model:
- DF2030
- Working envelope:
- X: 2000 / Y: 3000 / Z: 1200 mm
- Data transmission:
- Ethernet, USB, Wi-Fi
- File formats:
- STL, AMF, 3DMF
- Nozzle diameter:
- 2–6 mm
OVERVIEW
Large-format pellet extrusion supports near-net-shape tooling, mold patterns and prototypes. Confirm the material, service temperature, machining allowance and surface requirements before selecting a process. Materials must be qualified for the intended tooling duty. This equipment does not print metals.
STANDARD FEATURES
- Near-net-shape additive manufacturing
- Recyclable thermoplastic pellet materials
- Digital model changes without dedicated molds
- Machining allowance for controlled finishing
TECHNICAL PARAMETERS
| Model | DF2030 |
|---|---|
| Working envelope | X: 2000 / Y: 3000 / Z: 1200 mm |
| Data transmission | Ethernet, USB, Wi-Fi |
| File formats | STL, AMF, 3DMF |
| Nozzle diameter | 2–6 mm |
| Maximum heating temperature | 350 °C |
| Drive | AC servo |
| Structure | Steel welded structure with enclosed cover |
APPLICATIONS
- Mold and pattern making
- Automotive tooling
- Marine models
- Thermoforming
